UFP-20

UFP-20 — Advanced Water Leak Detection System

The UFP-20 is an advanced digital water leak detection system combining acoustic amplification with digital signal processing (DSP) to filter out background noise and enhance leak signal clarity. Compared to analogue ground microphones, the UFP-20 uses digital frequency analysis to display the leak noise spectrum, allowing the operator to identify the frequency band with the highest leak-to-noise ratio and improve detection accuracy in noisy urban environments (heavy traffic, underground infrastructure).

JS Civil Lab Solutions supplies the UFP-20 for water utilities, municipal water boards, and infrastructure contractors performing high-accuracy leak surveys on pressurised distribution systems.

Key Features

• Digital signal processing: Real-time frequency spectrum display (0–3,500 Hz)
• Smart filter: Automatically selects optimal frequency band for pipe material
• Sensors: Ground microphone, injection probe, and contact probe (set included)
• Amplification: 0–90 dB adjustable gain
• Display: Graphic LCD showing frequency spectrum and signal amplitude
• Recording: Audio and spectrum data logging with timestamp
• Bluetooth: Wireless headphone connection
• Battery: Rechargeable Li-ion, 8+ hours operating time

UFP-20 vs Standard Ground Microphone

A standard acoustic detector gives audio output only — the operator relies on hearing. The UFP-20 adds a visual spectrum display that shows the leak frequency signature versus background noise, making detection possible in high-noise environments (busy roads, market areas) where audio alone is unreliable. This reduces false-positive excavations significantly.

Enquire

Contact JS Civil Lab Solutions at +91 93596 24761 for a field demonstration and project-specific pricing.
