Heavy-Duty Concrete Mixing for Construction Sites & QA/QC Labs

90-Litre Concrete Mixer with Tilting Gearbox

The 90-Litre Concrete Mixer with tilting gearbox is designed for larger laboratory batches, pilot-scale concrete production, and site QC operations where a motorised tilting mechanism is needed for safe, controlled discharge of heavy concrete batches. The gearbox-driven tilt eliminates manual effort and ensures consistent discharge angle every time.

JS Civil Lab Solutions supplies 90 L tilting gearbox mixers for heavy-use concrete testing laboratories, NABL-accredited labs, and site QC operations handling multiple specimen sets per shift.

Specifications

• Capacity: 90 litres (effective batch)
• Motor: 2–3 HP, three-phase 415 V
• Tilting mechanism: Gearbox-driven (motorised) for safe discharge
• Drum speed: 20–25 rpm mixing speed
• Max aggregate size: 40 mm
• Construction: Heavy-gauge MS drum, epoxy-coated frame
• Compliance: IS 1791

Gearbox Tilt Advantage

At 90 L with wet concrete (~200 kg per batch), manual tipping is unsafe and inconsistent. The motorised gearbox tilt provides smooth, controlled discharge at the correct angle regardless of operator, reducing spillage and maintaining specimen quality — essential for NABL accreditation compliance.

Order

Contact JS Civil Lab Solutions at +91 93596 24761 for specifications and delivery to your lab.
